AMERICAN VOICED AMPLIFIERS

Bold, clear, thick.  These are all names synonymous with the 6V6GT power tube.  Single-ended or in Push-Pull they deliver tones as thick as Texas T-bones.  Country, Rock, Blues.  Yup.  They've done them all in style.  About all you need to decide is how soon you want it to break up and what speaker you want to match it with.

SPORT SERIES

Imagine the best of the Tweed amps combined with the features of the Blackface generation and you've imagined this amplifier.

Scale-able, versatile, fun.  That describes the Sport series of amplifiers.   All Sport amplifiers have the same reverb and preamplifier section.  The difference comes in the power supply and output section.  This amp can be built single-ended, the Rally Sport or push-pull, the Vintage Sport or Grand Sport.  The Rally Sport is a 5 watt single-ended 6V6 and the most basic version, but it still has decent headroom and breaks up nicely when pushed.  Don't love single-ended amps?  Want more power?  No worries.  The Vintage Sport is the low powered push-pull version with 12 watts from cathode biased 6V6s run in class AB.  Need a touch more headroom?  There's the Grand Sport version with a full 20 watts - very good clean headroom - and running those same 6V6s fixed bias in class AB.

All Sport Amplifiers Feature

  • (2) 12AX7 Preamp, (1) 12AT7 Reverb Driver

  • All Tube, Analog Spring Reverb

  • Volume, Treble, Bass, Reverb Level

  • 8 ohm Speaker Output (4/8/16 Available at Extra Charge)

  • Combo or Head Unit

  • Anodized, Engraved Aluminum Face Plate

Rally Sport Features

  • All Tube, Single-ended, Class A, Cathode biased 6V6 (5W RMS)

  • Solid State Rectifier

  • Contact for quote

Vintage Sport Features

  • All Tube, Push-pull, Class AB, Cathode biased 6V6's (12W RMS)

  • 12AX7 Parallel input stage, (1/2) 12AX7 Phase Inverter

  • GZ34 Tube Rectifier

  • Cab (Head) Dimensions - 22"W X 9-1/2"H X 9-1/2"D

  • $940 for Amplifier (not including Speaker or Cab) w/:

    • Tung Sol 6V6GT's

    • Tung Sol 12AT7

    • New Mullard 12AX7's

    • JJ GZ34

    • Hammond Power and Reverb Transformers

    • Mercury Magnetics Hand-wound Output Transformer

    • Sozo/Sprague/F&T Caps

  • B Custom Cabs Flame Maple Head Cabinet as shown = $510

Grand Sport Features

  • All Tube, Push-pull, Class AB, Fixed bias 6V6's (20W RMS)

  • 12AX7 Parallel input stage, (1/2) 12AX7 Phase Inverter

  • Solid State Rectifier

  • Contact for quote

Vintage Sport Front
Vintage Sport Front

press to zoom
Vintage Sport Rear
Vintage Sport Rear

press to zoom
Vintage Sport Rear ISO
Vintage Sport Rear ISO

press to zoom
Vintage Sport Front
Vintage Sport Front

press to zoom
1/4
V12 Front
V12 Front

press to zoom
V12 Front ISO
V12 Front ISO

press to zoom
V12 Back
V12 Back

press to zoom
V12 Front
V12 Front

press to zoom
1/6

VINTAGE 12

Have you ever heard a Blues or Rock recording from the 50’s or early 60’s that you absolutely fell in love with?  That thick clean sound with a hint of grit and natural tube compression… those smooth, buttery mids and sparkly highs… or maybe that fat, creamy overdrive.  Well if you have and you are looking for that tone, look no further! The Vintage 12 has the circuit, the components and the voicing to recreate those sought after pre-Marshall vintage tones.  Optimized for brighter single coil guitars like Stratocasters, Telecasters, and Broadcasters… you will find a wide palette of tones and dynamics to bring these guitars to their full potential. Hook up to your open back cab with Celestions or Jensens and take a trip down memory lane!

  • All Tube, Push Pull, Class AB, Cathode biased 6V6’s (12W RMS)

  • 12AY7 Preamp, 12AX7 Preamp/Phase Inverter

  • 5Y3GT Tube Rectifier

  • Normal and Bright Channels

  • Normal Volume, Bright Volume and Tone

  • Includes A/B pedal

  • 8 ohm Speaker Output (4/8/16 Available at Extra Charge)

  • Cab Dimensions – 14”W X 9-1/2”H X 9-1/2”D

  • Anodized, Engraved Aluminum Face Plate

  • $709 for Amplifier (not including Speaker or Cab) w/

    • Tung-Sol 6V6GT’s

    • New Mullard 12AX7

    • EH 12AY7

    • Sovtek 5Y3GT

    • Mercury Magnetics Hand-Wound Transformers

    • Sozo/Sprague/F&T Caps

  • $579 for Amplifier (not including Speaker or Cab) w/

    • EH 6V6GT's

    • EH 12AX7 & 12AY7

    • Sovtek 5Y3GT

    • Hammond Transformers

    • Mallory/Illinois Caps

  • Head Cabinet prices from $170, Cabinet Shown - B Custom Cabs Mahogany/Poplar Head Shell = $300

  • Combo options with a 12" speaker avaialble as well

Fulltone Front
Fulltone Front

press to zoom
Fulltone Rear
Fulltone Rear

press to zoom
Fulltone Front
Fulltone Front

press to zoom
1/2

FULLTONE

Vintage tone with modern updates! Single Ended, Class A, 6V6 power amp driven by a 12AX7 preamp with three way Focus switch and defeatable negative feedback. The Fulltone brings the best tone of the small amps of Fullerton, California into the 21st Century… a tone that can go from spankin’, twangy clean to raunchy overdrive with the twist of volume control. The three voicings of the "Focus" switch adjust midrange and bass focus and gain of the preamp to tailor your tone to any guitar. The "Boost" switch adds more gain at all frequencies. The negative feedback loop provides extended clean headroom and smoother highs when engaged and a more open tone to raw, aggressive crunch when disengaged.


  • All Tube, Single Ended, Class A, Cathode biased 6V6 (5W RMS)

  • 12AX7 Preamp with Switchable Negative Feedback Loop

  • GZ34 Tube Rectifier (5Y3GT May be used for Lower B+)

  • 3-way "Focus" switch changes the bass/midrange of the preamp

  • Volume, Tone, Negative Feedback and Focus Switches

  • 8ohm Speaker Output (4/8/16 Available at Extra Charge)

  • Cab (Head) Dimensions – 14”W X 9-1/2”H X 9-1/2”D

  • Anodized, Engraved Aluminum Face Plate

  • $609 for Amplifier (not including Speaker or Cab) w/:

    •  Tung-Sol 6V6GT

    • New Mullard 12AX7

    • JJ GZ34

    • Mercury Magnetics Hand-Wound Transformers

    • Sozo/Sprague/F&T Caps

  • $549 for Amplifier (not including Speaker or Cab) w/:

    • EH 6V6GT

    • JJ 12AX7

    • JJ GZ34

    • Hammond Power Transformer

    • Magnetic Components Output Transformer

    • Mallory/Illinois Caps

  • Tolex (or Tweed) Finger-jointed Pine Head Cabinet as shown = $170

  • Combo options with 10" or 12" speakers avaialble as well

MOD 5

MOD 5 is a high gain single tube preamp with a 6V6 output section with a single tone control, 3-way low end ‘Focus’ switch, and foot-switchable boost function.  This amp is a monster in a 5 watt package. Barely any clean headroom, this amp is for those who do mostly crunchy recordings and like the big, ballsy rip of a single ended 6V6 driven hard!  The amp is designed to be very tight on the lows with a slight midrange boost at full volume for a really thick tone – think humbuckers. The single tone control allows you to cut the highs at full gain and boost or brighten up at lower volumes – it is very interactive with the volume control yet does what it is supposed to do at each volume level.  Great for those who don’t like to fool with a bunch of controls yet I guarantee you will find a tone you like with a quick twist of just the simple volume and tone control setup!

  • All Tube, Single Ended, Class A, Cathode biased 6V6 (5W RMS)

  • 12AX7 Preamp

  • SS Rectifier

  • Tone and Volume Controls, 3-Way ‘Focus’ Switch, Boost Function w/ Footswitch and/or Panel Switch

  • 8 ohm Speaker Output (4/8/16 Available at Extra Charge)

  • Cab Dimensions – 14”W X 9-1/2”H X 9-1/2”D

  • Anodized, Engraved Aluminum Face Plate

  • Includes boost footswitch

  • $629 for Amplifier (not including Speaker or Cab) w/:

    • Tung-Sol 6V6GT

    • New Mullard 12AX7

    • Hammond Power Transformer

    • Mercury Magnetics Hand-Wound Output Transformer

    • Sozo/Sprague/F&T Caps

  • $539 for Amplifier (not including Speaker or Cab) w/

    • EH 6V6GT & JJ 12AX7

    • Hammond Power Transformer

    • Magnetic Components Output Transformer

    • Mallory/Illinois Caps

  • Head Cabinet prices from $170


6V6 Super Lead

The low power Plexi!  A modified 5F6A circuit, as all forms of Plexi's are, this one is more modern sounding closely following a 1959 Super Lead preamp.  The power amp puts out 10 watts of clean audio power through a special high impedance transformer and pushes a pair of 6V6's in true Class A operation with no negative feedback for plenty of harmonic content.  The results is an amp that has minimal clean headroom although excellent cleans in that range but more importantly a classic rock and roll tone at a more managable volume level.  Enough power for small club gigs and band practice but not so loud as to shake the paint off the walls in the studio.



  • All Tube, Push Pull, Class A, Cathode biased 6V6’s (10W RMS)

  • (2) Gain Stage 12AX7 Preamp + (1) 12AX7 Phase Inverter

  • Solid State Rectifier

  • Volume, Treble, Middle, Bass and Cut

  • 8 ohm Speaker Output

  • Mercury Magnetics Hand-Wound Transformers

  • Head Cab Dimensions – 18”W X 9-1/2”H X 9-1/2”D

  • Anodized, Engraved Aluminum Face Plate

  • Shown in combo form but can be built as a head unit

  • Contact for a quote

6V6 Super Lead Front
6V6 Super Lead Front

press to zoom
6V6 Super Lead Front ISO
6V6 Super Lead Front ISO

press to zoom
6V6 Super Lead Rear
6V6 Super Lead Rear

press to zoom
6V6 Super Lead Front
6V6 Super Lead Front

press to zoom
1/3
